Specifications
| Connection Vacuum Inlet Flange | DN 160 ISO-K |
| Connection vacuum outlet flange | DN 160 ISO-K |
| lubricantProductDefault | LEYBONOL LVO 330 |
| Power Total Rated | 7500.00 |
General Product Information
| Accessories / Scope of Supply | Mounting pad *4, ISO250 CO-SEAL PACK*1 |
| Connection vacuum outlet flange | DN 160 ISO-K |
| Connection Vacuum Inlet Flange | DN 160 ISO-K |
| Dimension Length | 1.28 |
| IP Rating | IP55 |
| Supply Frequency |
50 Hz
60 Hz |
| Power Supply Phase | 3-Ph |
| Weight | 452.00 |
| Dimension Comments | The dimensions length, width and height try to describe the outer shape of this particular product in its typical orientation when standing on the ground. We always recommend checking the detailed dimensions given in 2D drawings in the instruction manual or the 3D shapes given in 3D models. |
| Connection Inlet / Outlet Flange | DN 160 ISO-K | DN 160 ISO-K |
Environmental Conditions
| Temperature Ambient Operation Min | 12.00 |
Operation Conditions - Limitations
| Altitude Max | 3000.00 |
| Oil Capacity Max | 7.000 × 10⁻³ |
Classification
| Dry or Wet Pump | Dry |
| Product Pressure Range |
Medium Vacuum: 1 mbar - 1·10⁻³ mbar
Rough Vacuum: 1000 mbar - 1 mbar |
| High / Medium / Rough Vacuum Classification | Rough Vacuum Pump |
| Vacuum Pump Technology | Mechanical Booster Pump |
Performance Data
| Power Total Rated | 7500.00 |
| Minimum Roatational Speed | 9.00 |
| Maximum Rotational Speed | 66.00 |
Material of Construction
| Material Exposed to Vacuum | SG cast iron, SG iron, Steel |
Lubricants
| lubricantProductDefault | LEYBONOL LVO 330 |
